BPP1D5007QA

The BPP1D5007QA is a high voltage 1-Phase IPM(Intelligent Power Module). It integrates HVIC andhigh-performance MOSFET for BLDC and PMSMmotors. Separate Open-Source Pins from Low-SideMOSFETs are for Current-SensingThe input works with Schmitt-trigger and the logicvoltage level is compatible with 3.3V/5V/15V signal.UVLO and dead time are also provided

Built-in high-performance 500V/7A MOSFET

Built-in 600V Bootstrap diode

Robust at negative transient voltage

Gate drive supply range from 10V to 20V

3.3V, 5V and 15V input logic compatible

UVLO for both high side and low side

Built-in dead time to avoid cross-conduction

Available in QFN 9x9 package
