BPD95032

The BPD95032 is an up to 12 phase multi-phasebuck digital controller, which supports X+(12-X)phase for dual rail application. it provides a verycompact solution with minimized externalcomponents for high current level Core powersupply. The part supports l2C and PMBus Rev 1.3 withAVSBus for output control and telemetry. The CFV³M (Constant Frequency Voltage CubeModulation) auto loop compensation eases thesystem stability and provides fast transientresponse with optimized passive components.

Up to 12 Phase Dual Rail MultiphaseController

PMBus Rev 1.3 with AVSBus Interface forFast Telemetry

Built in NVM Configuration

Pin Programmable MCFG Function for EasyRegister Code Management

Fs 250k up to 2Meg Hz

External Phase Number Setting

Interleaving+/Phase Double/TLVR

Constant Frequency Lock Technology

• Graphic Card
• Server
• Telecom
