BPD80350E

The BPD80350E smart power stage fully integrates high speed drivers and low resistance half-bridge power switches. It offers comprehensive thermal monitoring and protection circuitry in an electrically and thermally optimized package. With a suitable high frequency control unit, this power stage forms a compact, high current voltage regulator system with prominent efficiency and transient response, excellently catering the needs of high current, high power density applications.

Input Voltage: 4.5V to 16V

50A Current Capability

High Frequency Operation (up to 1.5MHz)

3.3V/5V Compatible Tri-State PWM Input

Zero-Crossing Detection (ZCD) Control

Integrated Thermal Monitor

Over-Current Protection (OCP)

• High-Frequency, High-Current and Low-Profile DC/DC Converters
• Multiphase Voltage Regulators for CPUs, GPUs and Memory Arrays

•
