BPD95025

The BPD95025 is an up to 4+1 phase multi-phasebuck digital controller, which supports 4 phasesfor rail-1 and 1 phase for rail-2 application. ltprovides avery compact solution withminimized external components for highcurrent level Core power supply. The part supports l2C and PMBus Rev 1.3 withAVSBus for output control and telemetry. The CFV³M (Constant Frequency Voltage CubeModulation) auto loop compensation eases thesystem stability and provides fast transientresponse with optimized passive components.

Up to 4+1 Phase Dual Rail MultiphaseController

PMBus Rev 1.3 with AVSBus Interface for

Fast Telemetry

Built in NVM Configuration

Pin Programmable MCFG Function for EasyRegister Code Management

Fs 250k up to 2Meg Hz

External Phase Number SettingInterleaving+/Phase Double/TLVR

• Graphic Card
• Server
• Telecom
