BPD80370E

The BPD80370E smart power stage fullyintegrates high speed drivers and low resistancehalf-bridgeswitches. lt offerspowercomprehensive current and thermal monitoringand protection circuitry in an electrically andthermally optimized package. With a suitablehigh frequency control unit, this power stageforms a compact, high current voltage regulatorsystem with prominent efficiency and transientresponse, excellently catering the needs of highcurrent, high power density applications.

Input Voltage: 4.5V to 16V

70A Current Capability

High Frequency Operation (up to 1.5MHz)

3.3V/5V Compatible Tri-State PWM Input

Zero-Crossing Detection (zCD) Control

Integrated Current Monitor

Integrated Thermal Monitor

Over-Current Protection (OCP)

• High-frequency, high-currentand low-profile DC/DC converters
• Multiphase Voltage Regulators for CPUs,GPUs and Memory Arrays

•
