BP62560F

The BP62560F is an AC/DC secondary-side controller thatpairs with the BP87660F to achieve zero standby powerin fast charger applications.The BP62560F employs an output voltage ripple-basedcontrol algorithm that allows for fast transient responsewhile eliminating the need for complex loopcompensation circuits. BP62560F sends request signals tothe primary-side controller through the magnetic coupler BP818 to realize the regulation of the output voltage.

Zero no-load consumption (< 5 mW @ 230 Vac)

Controllable ultra-low-power sleep mode

Ripple-based control enables fast transient response

Supports CCM and QR operation

Feedback through magnetic coupling

Built-in synchronous rectifier controller

• QC/USB PD/ Programable AC/DC Chargers

•
