BPA8616PD

BPA8616PD is a highly integrated off-line switcher. It'sdesigned for Flyback application with universal input(85VAC-265VAC) range. By equipped with a series of advanced technology, itachieved high reliability, high performance, and lowsystem cost, reduced component countin the same time. For high reliability, it is integrated with 750V high voltagepower MOSFET. Current sensing circuit is also integrated toeliminate extra components and power consumption.

Integrated 750V power MOSFET

Self-biased

No-load power consumption <50mW at 230VAC with auxiliary winding, <150mW at 230VAC with selfbiasing

Excellent transient response, with no output overshoot

Internal soft start

• Home appliances
• PC standby power supply
• Communication, industrial controls

•
